Anti-Vibration Sheets
KG-GEL 80TW Sheet / TWG80 Series
Low hardness gel sheet with heat resistant properties. Isolates shockwaves from low frequencies and prevents them from travelling to devices.
Features:
- High temperature resistance.
- Flammability Rating Equivalent: UL 94-HB.
- Temperature Rating: -20C to +100C.
Lostomer AG Sheet / AGL Series
Anti-vibration cushioning, sound damping rubber sheet.
Features:
- Adhesive and non-adhesive options available.
- Isolates shock waves at low frequencies.
- Custom sizes available upon request.
Lostomer TPS Sheet / ALS20AF2-TC
Non-silicone sheet with non-tacky finish and high vibration damping performance.
Features:
- Good impact buffering.
- High durability and wear resistance.
- No leakage of silicone oil.
Lostomer TPS Sheet / ALS37V
High damping elastomer with flame retardance. Very high performance against vibration energy.
Features:
- High performance.
- Flammability Rating: UL 94-V-0.
- No silicone outgassing.
Low Hardness / Heat Resisitant / YMGS-95T Series
Ultra-soft silicone free gel for reducing structure borne vibration vibrations and shock control for lightweight enclosures.
Features:
- Heat resistant.
- No silicone outgassing.
- Suited for low frequencies.
Shock Absorbing Damper / G90VBK Series
Extremely soft material enables high shock absorbing performance for components, with higher performance at lower frequencies.
Features:
- Flammability Rating: UL 94-V-0
- No silicone outgassing.
Thermal Damping Sheet / CPAG Series
Dual function anti vibration sheet material that also functions as a thermal filler pad.
Features:
- Excellent vibration control (loss factor 0.9).
- Custom profiles can be provided upon request.
- No silicone outgassing.
